Container Truck Loading and Unloading Telescopic Belt Conveyor

Description

Telescopic belt conveyors, offer a safe and efficient loading and unloading solution. The main advantages are it’s simple operating system, and the ability to achieve a variety of positions by the operator extending and retracting the dock loader to its required position.

1. The operation buttons are clear and easy to use

2. The telescopic length can be controlled according to the demand

3. Color can be customized according to preference

4. Both mobile and fixed are available

Features

Model: LL-6/4 LL-6/8 LL-6/12 LL-6/14

Retracted: 6 6 6 6

Extended: 4 8 12 14

Total length: 10 14 18 20

Height: 0.75 0.8 1 1.2

Width of belt: 0.8 0.8 0.8 0.8

Width of conveyor: 1.38 1.4 1.47 1.53

Belt direction: Reversible

Loading capacity: 60kg

Belt speed: 0~36M/minute (adjustable)

Motor: 1.5kw 2.2kw 3.0kw 4.0kw

Weight: 2T 3T 4T 5T
